Compa V – versatile label printer

203 dpi

max 300 mm/s

104 mm

120 mm

min 20 mm

max 6000 mm

standard: min 5 mm

dispenser mode/cutter mode: min 15 mm

Flat Type for thermal direct print and thermal transfer print

continuous rolls or fan-fold: paper, cardboard, textile, synthetics

max 220 g/m² (other weight on request)

max 205 mm

Standard Ø 40 mm
Additional dimensions Ø 38.1 mm up to Ø 76 mm
(optional additional cores possible)

outside or inside

transmission and reflexion from below

outside or inside

max Ø 90 mm

25.4 mm / 1"

max 600 m

max 114 mm / 170 mm (Compa V 162)

252 x 288 x 460 mm

10 kg

TI Sitara ARM Cortex A8, 1GHz, 32kB ICache, 32kB DCache up to 2000 Mips

512 MB

for SD card

for real-time clock (data storage when shutdown)

acoustic signal when error

RS-232C (up to 115200 baud)

2.0 High Speed Slave

10/100 Base T, LPD, RawIP-Printing, DHCP

on the back for: keyboard, USB memory stick

110 … 240 V AC / 50-60 Hz

200 VA

2.5 A

5 … 35 °C

max 85 % (non-condensing)

test print, function menu, quantity, SD Card, feed, enter, 4 x cursor

graphic display 128 x 64 pixel

date, time, shift times

11 language settings (other languages on request)

label parameters, printer parameters, interfaces, password protection

end of ribbon, end of labels, printhead open

extensive status print with information about settings, e.g. print length counter, runtime counter, photocell, interface parameters, network parameters

printout of all internal fonts and all supported bar codes

6 bitmap fonts
8 vector fonts/TrueType fonts
6 proportional fonts
other fonts on request

Windows 1250 up to 1257, 437, 850, 852, 857, UTF-8

all West and East European, Latin, Cyrillic, Greek and Arabic (option) characters are supported

other character sets on request

size in width and height 0.8 … 5.6

zoom 2 … 9

orientation 0°, 90°, 180°, 270°

size in width and height 1 … 99 mm

variable zoom

orientation 0°, 90°, 180°, 270°

depending on character font

bold, italic, inverse, vertical

variable

2/5 Industrial, Codabar, Code 128, Code 128A, Code 128B, Code 2/5 interleaved, Code 39, Code 39 extended, Code 93, EAN 13, EAN 8, EAN Add-on, GS1-128, Identcode, ITF 14, Leitcode, Pharmacode, PLANET (Postal Alpha Numeric Encoding Technique), PostNet, PZN 7, PZN 8, UPC-A, UPC-E, USPS Intelligent Mail

Aztec Code, CODABLOCK F, DataMatrix, GS1 DataMatrix, MAXICODE, PDF 417, QR Code

GS1 DataBar Expanded, GS1 DataBar Limited, GS1 DataBar Omnidirectional, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional, GS1 DataBar Truncated

All bar codes are variable in height, module width and ratio
Orientation 0°, 90°, 180°, 270°
Optionally with check digit and human readable line

ConfigTool

NiceLabel

Labelstar Office | LITE

Labelstar Office

Printer Drivers

203 dpi

max 300 mm/s

104 mm

120 mm

min 20 mm

max 6000 mm

standard: min 5 mm

dispenser mode/cutter mode: min 15 mm

Flat Type for thermal transfer print

continuous rolls or fan-fold: paper, cardboard, textile, synthetics

max 220 g/m² (other weight on request)

max 205 mm

Standard Ø 40 mm
Additional dimensions Ø 38.1 mm up to Ø 76 mm
(optional additional cores possible)

outside or inside

transmission and reflexion from below

outside or inside

max Ø 90 mm

25.4 mm / 1"

max 600 m

max 114 mm / 170 mm (Compa V 162)

252 x 288 x 460 mm

10 kg

TI Sitara ARM Cortex A8, 1GHz, 32kB ICache, 32kB DCache up to 2000 Mips

512 MB

for SD card

for real-time clock (data storage when shutdown)

acoustic signal when error

RS-232C (up to 115200 baud)

2.0 High Speed Slave

10/100 Base T, LPD, RawIP-Printing, DHCP

on the back for: keyboard, USB memory stick

110 … 240 V AC / 50-60 Hz

200 VA

2.5 A

5 … 35 °C

max 85 % (non-condensing)

test print, function menu, quantity, SD Card, feed, enter, 4 x cursor

graphic display 128 x 64 pixel

date, time, shift times

11 language settings (other languages on request)

label parameters, printer parameters, interfaces, password protection

end of ribbon, end of labels, printhead open

extensive status print with information about settings, e.g. print length counter, runtime counter, photocell, interface parameters, network parameters

printout of all internal fonts and all supported bar codes

6 bitmap fonts
8 vector fonts/TrueType fonts
6 proportional fonts
other fonts on request

Windows 1250 up to 1257, 437, 850, 852, 857, UTF-8

all West and East European, Latin, Cyrillic, Greek and Arabic (option) characters are supported

other character sets on request

size in width and height 0.8 … 5.6

zoom 2 … 9

orientation 0°, 90°, 180°, 270°

size in width and height 1 … 99 mm

variable zoom

orientation 0°, 90°, 180°, 270°

depending on character font

bold, italic, inverse, vertical

variable

2/5 Industrial, Codabar, Code 128, Code 128A, Code 128B, Code 2/5 interleaved, Code 39, Code 39 extended, Code 93, EAN 13, EAN 8, EAN Add-on, GS1-128, Identcode, ITF 14, Leitcode, Pharmacode, PLANET (Postal Alpha Numeric Encoding Technique), PostNet, PZN 7, PZN 8, UPC-A, UPC-E, USPS Intelligent Mail

Aztec Code, CODABLOCK F, DataMatrix, GS1 DataMatrix, MAXICODE, PDF 417, QR Code

GS1 DataBar Expanded, GS1 DataBar Limited, GS1 DataBar Omnidirectional, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional, GS1 DataBar Truncated

All bar codes are variable in height, module width and ratio
Orientation 0°, 90°, 180°, 270°
Optionally with check digit and human readable line

ConfigTool

NiceLabel

Labelstar Office | LITE

Labelstar Office

Printer Drivers

300 dpi

max 300 mm/s

105,7 mm

120 mm

min 20 mm

max 3000 mm

standard: min 5 mm

dispenser mode/cutter mode: min 15 mm

Flat Type for thermal transfer print

continuous rolls or fan-fold: paper, cardboard, textile, synthetics

max 220 g/m² (other weight on request)

max 205 mm

Standard Ø 40 mm
Additional dimensions Ø 38.1 mm up to Ø 76 mm
(optional additional cores possible)

outside or inside

transmission and reflexion from below

outside or inside

max Ø 90 mm

25.4 mm / 1"

max 600 m

max 114 mm / 170 mm (Compa V 162)

252 x 288 x 460 mm

10 kg

TI Sitara ARM Cortex A8, 1GHz, 32kB ICache, 32kB DCache up to 2000 Mips

512 MB

for SD card

for real-time clock (data storage when shutdown)

acoustic signal when error

RS-232C (up to 115200 baud)

2.0 High Speed Slave

10/100 Base T, LPD, RawIP-Printing, DHCP

on the back for: keyboard, USB memory stick

110 … 240 V AC / 50-60 Hz

200 VA

2.5 A

5 … 35 °C

max 85 % (non-condensing)

test print, function menu, quantity, SD Card, feed, enter, 4 x cursor

graphic display 128 x 64 pixel

date, time, shift times

11 language settings (other languages on request)

label parameters, printer parameters, interfaces, password protection

end of ribbon, end of labels, printhead open

extensive status print with information about settings, e.g. print length counter, runtime counter, photocell, interface parameters, network parameters

printout of all internal fonts and all supported bar codes

6 bitmap fonts
8 vector fonts/TrueType fonts
6 proportional fonts
other fonts on request

Windows 1250 up to 1257, 437, 850, 852, 857, UTF-8

all West and East European, Latin, Cyrillic, Greek and Arabic (option) characters are supported

other character sets on request

size in width and height 0.8 … 5.6

zoom 2 … 9

orientation 0°, 90°, 180°, 270°

size in width and height 1 … 99 mm

variable zoom

orientation 0°, 90°, 180°, 270°

depending on character font

bold, italic, inverse, vertical

variable

2/5 Industrial, Codabar, Code 128, Code 128A, Code 128B, Code 2/5 interleaved, Code 39, Code 39 extended, Code 93, EAN 13, EAN 8, EAN Add-on, GS1-128, Identcode, ITF 14, Leitcode, Pharmacode, PLANET (Postal Alpha Numeric Encoding Technique), PostNet, PZN 7, PZN 8, UPC-A, UPC-E, USPS Intelligent Mail

Aztec Code, CODABLOCK F, DataMatrix, GS1 DataMatrix, MAXICODE, PDF 417, QR Code

GS1 DataBar Expanded, GS1 DataBar Limited, GS1 DataBar Omnidirectional, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional, GS1 DataBar Truncated

All bar codes are variable in height, module width and ratio
Orientation 0°, 90°, 180°, 270°
Optionally with check digit and human readable line

ConfigTool

NiceLabel

Labelstar Office | LITE

Labelstar Office

Printer Drivers

600 dpi

max 150 mm/s

105,6 mm

120 mm

min 20 mm

max 750 mm

standard: min 5 mm

dispenser mode/cutter mode: min 15 mm

Flat Type for thermal transfer print

continuous rolls or fan-fold: paper, cardboard, textile, synthetics

max 220 g/m² (other weight on request)

max 205 mm

Standard Ø 40 mm
Additional dimensions Ø 38.1 mm up to Ø 76 mm
(optional additional cores possible)

outside or inside

transmission and reflexion from below

outside or inside

max Ø 90 mm

25.4 mm / 1"

max 600 m

max 114 mm / 170 mm (Compa V 162)

252 x 288 x 460 mm

10 kg

TI Sitara ARM Cortex A8, 1GHz, 32kB ICache, 32kB DCache up to 2000 Mips

512 MB

for SD card

for real-time clock (data storage when shutdown)

acoustic signal when error

RS-232C (up to 115200 baud)

2.0 High Speed Slave

10/100 Base T, LPD, RawIP-Printing, DHCP

on the back for: keyboard, USB memory stick

110 … 240 V AC / 50-60 Hz

200 VA

2.5 A

5 … 35 °C

max 85 % (non-condensing)

test print, function menu, quantity, SD Card, feed, enter, 4 x cursor

graphic display 128 x 64 pixel

date, time, shift times

11 language settings (other languages on request)

label parameters, printer parameters, interfaces, password protection

end of ribbon, end of labels, printhead open

extensive status print with information about settings, e.g. print length counter, runtime counter, photocell, interface parameters, network parameters

printout of all internal fonts and all supported bar codes

6 bitmap fonts
8 vector fonts/TrueType fonts
6 proportional fonts
other fonts on request

Windows 1250 up to 1257, 437, 850, 852, 857, UTF-8

all West and East European, Latin, Cyrillic, Greek and Arabic (option) characters are supported

other character sets on request

size in width and height 0.8 … 5.6

zoom 2 … 9

orientation 0°, 90°, 180°, 270°

size in width and height 1 … 99 mm

variable zoom

orientation 0°, 90°, 180°, 270°

depending on character font

bold, italic, inverse, vertical

variable

2/5 Industrial, Codabar, Code 128, Code 128A, Code 128B, Code 2/5 interleaved, Code 39, Code 39 extended, Code 93, EAN 13, EAN 8, EAN Add-on, GS1-128, Identcode, ITF 14, Leitcode, Pharmacode, PLANET (Postal Alpha Numeric Encoding Technique), PostNet, PZN 7, PZN 8, UPC-A, UPC-E, USPS Intelligent Mail

Aztec Code, CODABLOCK F, DataMatrix, GS1 DataMatrix, MAXICODE, PDF 417, QR Code

GS1 DataBar Expanded, GS1 DataBar Limited, GS1 DataBar Omnidirectional, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional, GS1 DataBar Truncated

All bar codes are variable in height, module width and ratio
Orientation 0°, 90°, 180°, 270°
Optionally with check digit and human readable line

ConfigTool

NiceLabel

Labelstar Office | LITE

Labelstar Office

Printer Drivers

300 dpi

max 300 mm/s

108,4 mm

120 mm

min 20 mm

max 3000 mm

standard: min 5 mm

dispenser mode/cutter mode: min 15 mm

Flat Type for thermal direct print and thermal transfer print

continuous rolls or fan-fold: paper, cardboard, textile, synthetics

max 220 g/m² (other weight on request)

max 205 mm

Standard Ø 40 mm
Additional dimensions Ø 38.1 mm up to Ø 76 mm
(optional additional cores possible)

outside or inside

transmission and reflexion from below

outside or inside

max Ø 90 mm

25.4 mm / 1"

max 600 m

max 114 mm / 170 mm (Compa V 162)

252 x 288 x 460 mm

10 kg

TI Sitara ARM Cortex A8, 1GHz, 32kB ICache, 32kB DCache up to 2000 Mips

512 MB

for SD card

for real-time clock (data storage when shutdown)

acoustic signal when error

RS-232C (up to 115200 baud)

2.0 High Speed Slave

10/100 Base T, LPD, RawIP-Printing, DHCP

on the back for: keyboard, USB memory stick

110 … 240 V AC / 50-60 Hz

200 VA

2.5 A

5 … 35 °C

max 85 % (non-condensing)

test print, function menu, quantity, SD Card, feed, enter, 4 x cursor

graphic display 128 x 64 pixel

date, time, shift times

11 language settings (other languages on request)

label parameters, printer parameters, interfaces, password protection

end of ribbon, end of labels, printhead open

extensive status print with information about settings, e.g. print length counter, runtime counter, photocell, interface parameters, network parameters

printout of all internal fonts and all supported bar codes

6 bitmap fonts
8 vector fonts/TrueType fonts
6 proportional fonts
other fonts on request

Windows 1250 up to 1257, 437, 850, 852, 857, UTF-8

all West and East European, Latin, Cyrillic, Greek and Arabic (option) characters are supported

other character sets on request

size in width and height 0.8 … 5.6

zoom 2 … 9

orientation 0°, 90°, 180°, 270°

size in width and height 1 … 99 mm

variable zoom

orientation 0°, 90°, 180°, 270°

depending on character font

bold, italic, inverse, vertical

variable

2/5 Industrial, Codabar, Code 128, Code 128A, Code 128B, Code 2/5 interleaved, Code 39, Code 39 extended, Code 93, EAN 13, EAN 8, EAN Add-on, GS1-128, Identcode, ITF 14, Leitcode, Pharmacode, PLANET (Postal Alpha Numeric Encoding Technique), PostNet, PZN 7, PZN 8, UPC-A, UPC-E, USPS Intelligent Mail

Aztec Code, CODABLOCK F, DataMatrix, GS1 DataMatrix, MAXICODE, PDF 417, QR Code

GS1 DataBar Expanded, GS1 DataBar Limited, GS1 DataBar Omnidirectional, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional, GS1 DataBar Truncated

All bar codes are variable in height, module width and ratio
Orientation 0°, 90°, 180°, 270°
Optionally with check digit and human readable line

ConfigTool

NiceLabel

Labelstar Office | LITE

Labelstar Office

Printer Drivers

300 dpi

max 250 mm/s

162,6 mm

180 mm

min 46 mm

max 2000 mm

standard: min 5 mm

dispenser mode/cutter mode: min 25 mm

Flat Type for thermal direct print and thermal transfer print

continuous rolls or fan-fold: paper, cardboard, textile, synthetics

max 220 g/m² (other weight on request)

max 205 mm

Standard Ø 40 mm
Additional dimensions Ø 38.1 mm up to Ø 76 mm
(optional additional cores possible)

outside or inside

transmission and reflexion from below

outside or inside

max Ø 90 mm

25.4 mm / 1"

max 600 m

max 114 mm / 170 mm (Compa V 162)

312 x 288 x 460 mm

14 kg

TI Sitara ARM Cortex A8, 1GHz, 32kB ICache, 32kB DCache up to 2000 Mips

512 MB

for SD card

for real-time clock (data storage when shutdown)

acoustic signal when error

RS-232C (up to 115200 baud)

2.0 High Speed Slave

10/100 Base T, LPD, RawIP-Printing, DHCP

on the back for: keyboard, USB memory stick

110 … 240 V AC / 50-60 Hz

200 VA

2.5 A

5 … 35 °C

max 85 % (non-condensing)

test print, function menu, quantity, SD Card, feed, enter, 4 x cursor

graphic display 128 x 64 pixel

date, time, shift times

11 language settings (other languages on request)

label parameters, printer parameters, interfaces, password protection

end of ribbon, end of labels, printhead open

extensive status print with information about settings, e.g. print length counter, runtime counter, photocell, interface parameters, network parameters

printout of all internal fonts and all supported bar codes

6 bitmap fonts
8 vector fonts/TrueType fonts
6 proportional fonts
other fonts on request

Windows 1250 up to 1257, 437, 850, 852, 857, UTF-8

all West and East European, Latin, Cyrillic, Greek and Arabic (option) characters are supported

other character sets on request

size in width and height 0.8 … 5.6

zoom 2 … 9

orientation 0°, 90°, 180°, 270°

size in width and height 1 … 99 mm

variable zoom

orientation 0°, 90°, 180°, 270°

depending on character font

bold, italic, inverse, vertical

variable

2/5 Industrial, Codabar, Code 128, Code 128A, Code 128B, Code 2/5 interleaved, Code 39, Code 39 extended, Code 93, EAN 13, EAN 8, EAN Add-on, GS1-128, Identcode, ITF 14, Leitcode, Pharmacode, PLANET (Postal Alpha Numeric Encoding Technique), PostNet, PZN 7, PZN 8, UPC-A, UPC-E, USPS Intelligent Mail

Aztec Code, CODABLOCK F, DataMatrix, GS1 DataMatrix, MAXICODE, PDF 417, QR Code

GS1 DataBar Expanded, GS1 DataBar Limited, GS1 DataBar Omnidirectional, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional, GS1 DataBar Truncated

All bar codes are variable in height, module width and ratio
Orientation 0°, 90°, 180°, 270°
Optionally with check digit and human readable line

ConfigTool

NiceLabel

Labelstar Office | LITE

Labelstar Office

Printer Drivers
